| Capacity (Ton) | 4 Ton | |
| Refrigerant | R22 | |
| Color | White |
| Capacity | “Cooling Capacity KW” | 14 |
| “Cooling Capacity (BTU)” | 4800 | |
| Heating Capacity (BTU) | 5200 | |
| Air Circulation (m3/h) | 1800 | |
| Rated Power input (KW) Cooling | 4.92 | |
| Rated Power Input (KW) Heating | 5.08 | |
| Power Supply (Ph/V/Hz) | 3/380-415/50 | |
| EER/COP(W/W) | 2.84/2.95 |
| Piping Connection | Gas Side Dia (mm) | 19.05 |
| Liquid Side Dia (mm) | 9.52 | |
| Max Pipe Length (m) | 50 | |
| Max Drop (m) | 30 |
| Warranty | Warranty | 1 year Parts, 5 Years compressor |
| Dimensions | Indoor Net Dimension W/D/H | 930/930/390 |
| Indoor Packing Dimension W/D/H | 1008/410/830 | |
| Outdoor Net Dimension W/D/H | 1130/490/930 | |
| Outdoor Packing Dimension W/D/H | 1130/490/930 | |
| Panel Net Dimension W/D/H | 950/950/60 | |
| Panel Packing Dimension W/D/H | 992/992/115 |
| Weight | Indoor Gross weight (Kg) | 31 |
| Indoor Net weight (Kg) | 31 | |
| Outdoor Gross Weight (Kg) | 96 | |
| Outdoor Net Weight (Kg) | 88 | |
| Panel Gross Weignt (Kg) | 7.7 | |
| Panel Net Weignt (Kg) | 5.3 |
| Noise | Indoor Noise [db(A)] (Hi/Mid/Lo) | 50/46/42 |
| Outdoor Noise [db(A)] | 61 |
